Leica FlexLine TS06 Plus R500 Reflectorless Total Station

The Leica FlexLine TS06 Plus is designed to meet mid to high applications and comes standard with a full alphanumerical keyboard, host USB and built-in Bluetooth to make the TS06plus quicker and more convenient to use.

Original price was: $7,900.00.Current price is: $4,900.00.

In stock

SKU: Leica TS06 Plus Category: Tag:


Top precision meets high efficiency

Leica FlexLine TS06 Plus delivers measurements that are extremely precise from a selection of Electronic Distance Measurements (EDM) options. Specifically designed for applications of medium accuracy it comes with the easy setup with a laser plummet and guided process at start-up. The ergonomic key layout and large display provides error-free data input and makes operation simple.

Features of the Leica FlexLine TS06 Plus include a built-in easy to use an alphanumerical keyboard for fast entry of numbers, special characters, and numbers. This not only increases speed and productivity but also minimizes errors.

The Flexline TS06 Communication Side Cover allows for connections to any data collector via a cable-free Bluetooth connection. It is ideally used with Leica Viva CS10 or Leica CS15 using SmartWorks software. The USB functionality gives transfer flexibility of data files including GSI, ASCII, DXF, CSV, and more. The Flexline TS06 also has a large internal memory and can store up to 100000 fix points and 60000 measurements.

This Total Station uses Lithium-Ion batteries for long life, fast charging, and an operation time of 30 hrs. The Flexline weighs 5.1kg including the GEB211 battery and tribrach. Its the container is light, tough, and keeps the instrument with all the accessories dust and waterproof.

The First Plus: Original Leica Geosystems quality

For most, “quality” is relative. Not so at Leica Geosystems. To ensure our instruments meet the highest precision and quality requirements, we manufacture them in state-of-the-art facilities around the world. Swiss technology combines with exceptional craftsmanship to provide best-in-class devices. And this quality also applies to all of our procedures – moving Leica Geosystems towards business excellence to meet our customers’ needs and expectations in every way.

The Leica FlexLine TS06plus manual total station is ideal for many daily surveying tasks, especially for mid- to high-accuracy applications. Banking on the heritage of the previous TS06 model, the most successful of the Leica FlexLine Series, the FlexLine TS06plus is the newest ultimate total station.


The Second Plus: Real features, true benefits

  • USB Stick: For fast and easy transfer of data
  • Wireless Bluetooth: For cable-free connection to a data logger
  • Electronic Guide Light: For faster stake-out
  • FlexField plus: Modern and intuitive onboard software for higher productivity
  • Useful tools: A range of tools, such as a trigger key and laser plummet, speed up your work
  • PinPoint EDM
    – The most precise in its class (1.5 mm + 2 ppm)
    – Extremely fast (1 second)
    – > 1,000 meters without prism „„
    – Coaxial laser pointer and measurement beam
  • Alpha-numerical keyboard
    -Fast and error-free input
  • Large high- resolution display
    -At-a-glance viewing on the largest high-resolution display in its class
  • Arctic version
    – For use at –35°C (–31°F)
  • mySecurity
    – Unique theft protection locking mechanism

The Third Plus: Top precision, speed, and efficiency

The claim “easy-to-operate” seems to be everywhere. Whether this promise can be kept only becomes apparent in the practice. Because professional measurement experts were involved in its development, the Leica FlexLine TS06plus allows you to work quickly and effectively right from the first day.

Electronic Distance Measurement
Wherever high-distance measurement accuracy is required, you can face the challenge of this demanding task with the TS06plus. It provides the most accurate Electronic Distance Measurement.

  • Prism Mode
    – Precision+ (1.5 mm + 2 ppm) „„
    -Speed (1 second)
  • Non-Prism Mode
    -Precision (2 mm + 2 ppm)
    -PinPoint EDM with a coaxial, small laser pointer and measurement beam for accurate aiming and measuring
    -Fewer set-ups required because targets on which it is not possible to set up a reflector can be measured using reflectorless measurement up to 1,000

Built-in user-friendliness: The full alpha-numerical keyboard.
The Leica TS06plus standard built-in the alpha-numerical keyboard enables fast and easy entry of numbers, letters, and special characters, e.g. for coding. It increases the work speed while at the same time reducing possible sources of error. FlexField plus onboard software: Easy-to-use due to its graphical guidance and intuitive workflows.

The Leica FlexLine TS06plus communication side cover enables cable-free connection to any data collector via Bluetooth®, for example, the field-controllers Leica CS20 controller or Leica CS35 tablet with Captivate software. The USB-stick enables the flexible transfer of such data as GSI, DXF, ASCII, LandXML, and CSV.

 Leica TS06 Plus Total Station Included:

  • Leica TS06 Plus Total Station
    – Bluetooth
    – R500 500M Reflectorless Measurement
    – Calibrated By A Leica Certified Service Center
  • Leica GKL311 Battery Charger w/ AC Adapter
  • Leica Charging Cable
  • Leica GMP111-0 Prism
  • Leica Rain Cover
  • QTY. 4 Extension Rods
  • Leica FlexLine Plus Quick Guide
  • Polishing Cloth
  • DC Car Charger
  • QTY. 2 Battery Packs
  • Lens Hood Protector
  • Hard Carrying Case
  • Charger GKL311
  • Leica Data Cable
  • lens cover +Rain cover
  • Manual
  • Tribrach
  • Li-Ion rechargeable battery

Reference Library

Leica FlexLine TS06 Plus R500 Reflectorless Total Station Manufacturer Information
Leica FlexLine TS06 Plus R500 Reflectorless Total Station Brochure
