Leica Viva TS15 R30 1″ Robotic Total Station

Leica Viva TS15 adds an advanced image sensor to the already proven total station sensors. With unique capture-sketch-link functionality, total station images can be captured, enhanced with sketching, and linked to any point of interest.

Original price was: $12,950.00.Current price is: $7,500.00.

In stock

SKU: Leica Viva TS15 Category: Tag:


Leica’s Viva TS15 provides advanced imaging functionality combined with dynamic tracking capabilities for one-person surveying.

Leica Viva TS15 provides advanced imaging functionality combined with dynamic tracking capabilities for one-person surveying. Leica Viva TS15 features the easy-to-use Leica SmartWorx Viva onboard software.

The Leica Viva TS15 adds a high-resolution camera to further enhance total station productivity. Traditional robotic operation is significantly improved with imaging features through Image Assisted Surveying and Documentation.

The Leica TS15 now includes new grid scanning functionality. It is now easily possible to graphically define an area to be scanned on the total station view shown on the display. The total station will then rapidly scan the object to measure a true grid with survey accuracy.

The Leica Viva TS15 incorporates Leica SmartWorx Viva onboard software to fully harmonize Leica Viva CS10 and CS15 controllers and the Viva TS15 total station on one easy-to-use productive software platform. Leica SmartWorx Viva provides a wide range of applications.

The Leica Viva TS15 models offer angle measurements of 1”, 2”, 3”, and 5” with quadruple axis compensation. In prism mode, a distance of 3’500m is achieved with an accuracy of 1mm+1.5ppm on a single prism in standard measuring mode. On all surfaces, users can measure up to 1’000 m and more with an accuracy of 2mm + 2ppm.

Users can add full GNSS functionality to the Leica Viva TS15 total station to further improve productivity. The TS15 can be used as a Leica SmartStation for TPS setup without the need of control points, traverses, and resections, or as a Leica SmartPole to save time with setup ‘On-the-fly’ and measure parallel with TPS and GNSS for double productivity.




Best-in-class Imaging

Optimize your productivity with exact photo documentation of site conditions. With live streaming of the total station view, you always know what the total station sees. Measure all points without returning to the total station.
– Image Notes – Capture an image, screenshot or template, sketch on it and link it to any object in the database
– Image Assisted Surveying – Simply tap on the display and the total station will turn and measure the desired target

Key components for the imaging functionality of the TS15 I are:

– High-quality optics (no distortions, fixed focus)
– High-resolution sensor (5 Mpx CMOS image sensor)
– The high-performance image-processing board
– High-speed slip rings
– High-performance processor (Freescale i.MX31, 533 MHz multimedia processor with integrated image processing unit)
– High-resolution display (full VGA display)

Best-in-class One-Person-Surveying

Viva TS15 uses years of experience to optimally combine the world’s best total station sensors: angles, distances, drives, and the patented PowerSearch target recognition camera.
– Search – the unique PowerSearch finds your prism within seconds
– Lock – Viva TS15 stays locked onto your prism in the most demanding environments
– Measure – PinPoint EDM seamlessly harmonizes with precise angle sensors to complete the measurement process

Leica Viva GNSS Add-on

Add full GNSS functionality to your Viva TS15 whenever you want and combine TPS and GNSS in the most efficient way.
– Use SmartStation for TPS setup without the need for control points, traverses, and resections
– Use SmartPole to save time with setup “On-the-fly” and measure parallel with TPS and GNSS for double productivity

Leica Viva TS15 R30 Included:

  • 1x Leica TS15 R30 1″ Robotic Total Station c/w tribrach
  • Calibration Certificate Provided Upon Request.
  • Leica GEB221 Battery
  • Charger
  • New 2GB SD Card
  • Leica Hard Case
  • RH16 Radio Handle
  • Leica Red Hard-case
  • Rain Cover & Scope Cover
  • 2x GEB221 Batteries
  • Instruction booklets
  • GKL311 Charger (c/w car charger lead)
  • Leica SD Card (MSD1000)
  • Data transfer cable
  • SmartWorx Viva TS Licence Key
  • Viva TS Imaging License
  • GDF121 Tribrach without Plummet
  • GEV189 Cable TPS/DNA – USB
  • GKL221 Charging Station
  • GDI221 Charging Adaptor for Li-Ion Battery
  • MSD1000 Industrial Grade SD Memory Card 1GB
  • GLS12 Aluminium SmartPole, Telescopic Snap-lock, CM
  • GRZ4 360° Prism
  • 1 yr Viva TPS TS15 Basic Customer Care Package
  • Active Assist for Leica Viva TS15
